Introducing the Komfort LOWLay18 UFH Overlay panel is an ideal solution for achieving efficient underfloor heating (UFH) beneath wood or tile floor finishes. Its design simplifies installation, making it suitable for various renovation or new build projects, whether on ground floors or upper levels. When paired with ceramic flooring, the system can deliver an impressive heating output of up to 99 watts/m², contingent on the specific floor finishes being used.
TECHNICAL DATA:
- Pipe Dimensions: 10 or 12mm Pipe
- Pipe Centres: 150mm
- First Reaction Class: A2
- Density: 1100-1200 kg/m3
- Water Vapor Permeability: µ = 13
- Thermal Conductivity: ?= 0,32 W / mK
- Characteristic Heat Capacity: c= 1,1 kJ / kgK
- Brinell Hardness: 30 n / mm2
- Coefficient of Thermal Expansion: 0,001 % K
- Dimensions: L800 x W600 x D18mm
How many boards do you need? Calculation Example: 20m2 divide by 0.48 = 42 Panels.
Constructed from non-flammable Fermacell Gypsum Fibreboard, these 18 mm panels are part of the Dry Flooring Elements (DFE) range, ensuring high-quality performance and safety. The KomLow18 is compatible with existing heating systems that utilize 150 mm pipe centres and accommodate 12 mm pipe, offering versatility and ease of integration. Overall, the Komfort KomLow18 provides an effective and efficient solution for modern heating needs while maintaining aesthetic appeal.
The Komfort Overlay panels are the ideal when installing because each panel comes with straight runs and returns, this allows the 800mm x 600mm universal panels and our 12mm 5 Layer PERT-AL-PERT Oxygen Barrier UFH Pipe to be installed with greater ease, making it one of the most flexible overlay fixing systems in the market, allowing a choice of system layouts.
